HN4 Series 304 Stainless Steel Freestanding Enclosures - NEMA 4X
Single Door, 3pt Handle
Application
- Designed to house electrical, electronic, hydraulic or
pneumatic controls with provision for panel mountÂing or rack mounting
of equipment.
- Provides protection where equipment may be hosed down or
otherwise be very wet, or in specific applications where corrosion is a
serious problem.
- A variety of inner panels, rack mounting rails and swing
out frames are available to provide flexibility in mounting
arrangements.
Standards
- UL 508 Type 3R, 4X and 12
- CSA Type 3R, 4X and 12
- Complies with:
- NEMA Type 3R, 4X, 12 and 3
- IEC 60529, IP66
Construction
- Formed 12 gauge steel.
- 304 stainless steel.
- Smooth, continuously welded seams without knockouts, cutouts or holes.
- Lifting eyes provide for easy enclosure handling.
- Doors are supported with heavy gauge continuous hinges.
- New 3-pt padlocking door handle.
- Oil resistant gaskets are permanently secured and mechanically retained.
- A grounding stud is provided in the enclosure and a bonding stud is provided on the door.
- Mounting channels are welded on the inside of the enclosure for mounting of optional inner panels or rack equipment rails.
Finish
- Cover and enclosure are natural stainless steel with a smooth brushed finish.
- Optional inner panels are finished in white powder paint.
Accessories
- Air conditioners
- Breather kits
- Door stop kits
- Filter fans
- Heaters
- Inner panels
- Panel rails
- Swing frame
- Thermostats
- Window kits
|
|
|
